The VN7004CHTR from STMicroelectronics is a robust, high-side driver that is part of the VIPower M0-7 series. It is designed to drive automotive applications by providing a high current drive capability with a minimal RDS(on). This makes it an ideal choice for driving resistive, inductive, and capacitive loads, including filament lamps, solenoids, and DC motors.

Key Features

• Integrated Current Limit: The device features an active current limitation to protect the power switch from overload conditions.
• Thermal Shutdown: With built-in thermal shutdown, the VN7004CHTR ensures safe operation by turning off the output when the junction temperature exceeds the threshold.
• High Voltage Capability: The high-side driver can handle a wide range of supply voltages, which is essential for automotive applications that experience voltage fluctuations.
• Diagnostic Feedback: The VN7004CHTR provides diagnostic feedback through a status pin that can indicate open load in the OFF state, overtemperature shutdown, and overload conditions.

Applications

Thanks to its rugged design and high reliability, the VN7004CHTR is well-suited for various automotive applications such as:

• Headlamp and rear lamp driving
• DC motor control in HVAC systems
• Control of valves and other actuators

Technical Specifications

The device is encapsulated in a compact HSSOP24 package, which is designed to minimize space on the PCB. It is capable of driving loads up to 40V with an on-resistance of just 4 mOhm. The VN7004CHTR is designed to handle a high continuous current up to 70A, depending on the case temperature.

Quality and Reliability

STMicroelectronics is known for its commitment to quality and reliability, and the VN7004CHTR is no exception. It is built to meet the stringent requirements of the automotive industry, including extended temperature ranges and resistance to harsh environments.
