Product Overview: BZV55-C16 by NXP Semiconductors

The BZV55-C16 is a high-quality, small signal Zener diode produced by NXP Semiconductors, a leader in the electronics industry. This compact component is specifically designed to offer a stable and precise voltage regulation solution for a wide range of applications. With its Zener voltage of 16V, the BZV55-C16 is commonly used in voltage stabilization scenarios, ensuring consistent performance across various electronic circuits.

Key Features

• Zener Voltage (Vz): 16V, providing a reliable reference voltage for various applications.
• Package: The diode comes in a small and lightweight LLDS (MiniMELF) SOD-80C package, suitable for high-density mounting and saving valuable board space.
• Power Dissipation: Capable of dissipating up to 500mW of power, ensuring adequate handling of energy within the circuit.
• Tolerance: Precision Zener voltage tolerance of approximately ±5%, allowing for accurate voltage regulation and stable circuit operation.
• Operating Temperature Range: Designed to operate effectively within a wide temperature range, typically from -65°C to +175°C, making it suitable for extreme conditions.
• Non-repetitive Peak Reverse Power: Can handle surge energy up to 2W for short durations, providing transient voltage protection.

Applications

The BZV55-C16 is versatile and can be used in various electronic applications including:

• Power supply regulation
• Overvoltage and surge protection circuits
• Consumer electronics voltage reference
• Industrial electronics
• Telecommunication devices

Quality and Reliability

NXP Semiconductors is committed to delivering high-quality components. The BZV55-C16 is manufactured with the latest semiconductor technology, ensuring high reliability and performance consistency. Each diode is subjected to rigorous testing and quality control measures, guaranteeing that it meets the stringent standards expected by the industry.

Whether you are designing power management systems, consumer electronics, or industrial machinery, the BZV55-C16 Zener diode from NXP Semiconductors is an excellent choice for maintaining voltage stability and protecting sensitive electronic components.
